OK-560-3GB full-auto cellophane wrapping machine
Applications and Features:：
1、This machine is widely used for automatic packaging of large, medium, and small box-shaped products, either single package or in bundle package. It utilizes a PLC human-machine interface, with the main drive controlled by a servo motor. The servo motor infeed the film, allowing for flexible adjustment of film size. The machine platform and parts contacting the packaged product are made of stainless steel, meeting hygiene standards. Only a few parts need to be replaced to package boxes of varying sizes.
2、This dual-servo drive system provides high speed and excellent stability, making it an ideal choice for three-dimensional packaging of various sizes and varieties.
3、 Optional devices include a tear line mechanism, automatic box turning mechanism, box stacking mechanism, six-side ironing mechanism, and date printer.
Technical Parameter
| Model | Power Supply | Total Power | Packing Speed(Boxes/min) | Box dimension(mm) | Outline Dimension(mm) |
| OK-560-3GB | 380V/50HZ | 6.5KW | 30-50 | （L）50-270（W）40-200（H）20-80 | （L）2300（W）900（H）1680 |
| Remark:1.Length and thickness cannot reach both upper or lower limits；
2.Width and thickness cannot have both upper or lower limits； 3.Packaging speed depends on the hardness and size of the packaging material； |
|||||
