OK-701 Type Round, Flat Toilet Tissue Universal Log Saw Cutting Machine

Short Description:


Product Detail

Product Tags

Model & Main Technical Parameters

Model

OK-701A

OK-701B

Cutting length Variable,Servo control, Tolerance:±1mm
Designing speed 0-150 cuts/min 0-250 cuts/min
Stable speed 120 cuts/min 200 cuts/min
Function type Movement of round blade in revolved swing and continuous and onward movement of paper roll with control
Driving control for material conveying Drived by servo motor
Blade-grinding Pneumatic grinding wheel,which the grinding time can be programming controlled by panel
Blade-greasing Greasing by spraying oil reek, which the greasing time can be programming controlled by panel
Outer dia, of round blade for paper slitting

610mm

Parameter setting

Touch screen

Programming control

PLC

Power

12KW

22KW

Cutting lane

1-2 lane
