OK-10 Type Handle Maker Machine

Short Description:


Product Detail

Product Tags

Main Performance And Structure Features

1.Packing forms such as automatic material feeding, film feeding, slitting, handle feeding, handle fixing, etc. are adopted. Compact and reasonable structure, simple operation and adjustment.

2.Servo motor, touch screen, PLC control system and man-machine interface display make operation more clear and convenient. With high automation degree, the machine is more user-friendly.

3.The automatic material arranging and conveying mechanism is adopted to facilitate linked production with automatic production line, which can greatly reduce labor cost.

4.The photoelectric eye automatic detection tracking system is adopted. No handle feeding is made if there is no material, so as to save packing materials to the utmost extent.

5.With wide packing range and convenient adjustment, fast switching among various specifications and sizes can be realized.

6.No need changing moulds for specification change, but can be realized through adjustment.

7.Handle width can be adjusted and set according to customer needs.

8.Hot handle fixing can be adopted according to customer requirements.

Model & Main Technical Parameters

Model

OK-10

Production capacity(packs/min)

≤50

Packing specification(mm)

L≤700, W≤260,H≤130

Outline dimension(mm)

L1990xW1100xH1780

Power Consumption (KW)

3

Machine’s Weight (KG)

800

Power supply

380V 50Hz

Compressed air pressure(MPA)

0.6

Air consumption (L/min)

120-160L
