Model

OK-906

Finished Size

L:200-400 mm

W:125-220 mm

H:85-110 mm

Speed

Designing speed

65 bags/min

Production speed

60 bags/min

 (depend on product specification )

Power supply

motor power

33 Kw

host heating power

2.4Kw

Total machine’s weight

3000KG

double bag storage structure

Each bag storage Can store 450-500 bags

Outline dimension

2670mm×1860mm×1610mm

（Length x width x height）

type of power supply

380V 50HZ

compressed air pressure consumption

6kg/cm2    0.116m3/min

Machine noise

≤75db

Note: Due to different packaging materials and different machine configuration requirements, the above data may differ from the actual data.
