OK-250 Type Double Lanes High-Speed Handkerchief Tissue Production Line

Short Description:


Product Detail

Product Tags

Main Performance And Structure Features

1.Adopt “U” structure and layout, continuously folding and packing, beautiful appearance, smooth packing process, stable and reliable structure.

2.Constant tension control raw paper’ s running, step-less regulation polishing speed for tissue.

3.Adopt BST raw paper automatic traverse rectifying, mini-type and standard-type tissue’s package are applicable.

4.Programmable controller to control intensively, operate by touch screen, with the function of displaying failure and warning, automatically stopping and protection, statistics data.

5.Paper size and quantity of each bag can be made according to the

Customer’ s demand. Such as paper size can be 200mm×200mm,210 ×210mm etc, quantity of each bag 81012 pieces etc.

6.Other selective functions: embossing roller, perforation device and automatic labeling machine, can be matched our handkerchief tissue bundling packing machine.

Model & Main Technical Parameters

Model

OK-250

Speed(bags/min)

≤250

Raw paper width(mm)

410mm-420mm

Paper size(mm)

200mmx200mm,210mmx210mm

Pieces of each bag

6,8,10

Packing size(mm)

(70-110)x(50-55)x(16-28)

Outline Dimension(mm)

7500x3900x2100

Machine’s Weight(KG)

5000

Total Power(KW)

45

Power supply

380V  50Hz

Packing Film

CPP,PE,BOPP and double-side heat sealing film
